Axon Motor
1 / 5
| Model | Voltage (V) |
Start Voltage (V) |
No-load | Starting torque (Kg.cm) |
Stall | ||
|---|---|---|---|---|---|---|---|
| Speed (r/min) | Current (mA) | Speed (r/min) | Current (A) | ||||
| KC-545PH-4560 | 12.0 | 0.7 | 7597 | 337 | 2.5 | 7039 | 1.7 |
| KC-545PH-2968 | 24.0 | 0.9 | 6989 | 229 | 2.6 | 6055 | 1.8 |
Established in August 2009, our enterprise integrates the research and development, production, and marketing of high-quality micro motor series products. Our primary offerings include precision DC motors, stepper motors, reduction motors, planetary reduction motors, and brushless motors.
These micro motors are widely utilized across multiple industries, including medical equipment, medical detection and analysis, financial security, 5G applications, automotive appliances, intelligent communication, iris recognition systems, AI intelligence, smart grids, smart home products, commercial smart locks, smart medicine cabinets, wearable devices, outdoor equipment, intelligent robots, and power tools.
Adhering to the core philosophy of innovation and efficiency, we leverage advanced production facilities, efficient management, and rigorous quality control to deliver optimal services that enhance product performance, lower energy consumption, and increase production efficiency for our global clientele.
A1: We provide flexible shaft customizations, including D-shaped shafts, threaded designs, screw leads, specific lengths, and diameter adaptations to match your target installation requirements.
A2: Yes, the RS-545 is designed to support both CW and CCW rotation. The direction can easily be reversed by switching the polarity of the input voltage terminals.
A3: The standard rated operating voltage range is from DC 6V to 24V, allowing it to easily adapt to standard industrial, automotive, and battery-powered applications.
A4: The RS-545 features high-performance carbon brush commutation, which provides a balance of long working life, high efficiency, and stable current transfer.
A5: This motor is widely used in medical analysis tools, smart security locks, smart home appliances, robotic components, power tools, automotive electrical units, and outdoor smart devices.
A6: Our motors comply with international quality guidelines, achieving standard safety and performance certifications to ensure safe integration into global commercial markets.
