Axon Motor
1 / 5
| GM12-N20-09170-3.0V Technical Specifications | |||||||||
| Parameter | Value 1 | Value 2 | Value 3 | Value 4 | Value 5 | Value 6 | Value 7 | Value 8 | Value 9 |
|---|---|---|---|---|---|---|---|---|---|
| Reduction Ratio | 10 | 30 | 50 | 100 | 150 | 210 | 250 | 298 | 330 |
| Gearbox Length (mm) | 9 | 9 | 9 | 9 | 9 | 9 | 9 | 9 | 9 |
| No-load Speed (rpm) | 960 | 320 | 192 | 96 | 64 | 46 | 38 | 32 | 29 |
| Rated Speed (rpm) | 730 | 243 | 146 | 73 | 49 | 35 | 29 | 24 | 22 |
| Rated Torque (kg.cm) | 0.02 | 0.04 | 0.06 | 0.12 | 0.15 | 0.21 | 0.25 | 0.30 | 0.33 |
| Stalling Torque (kg.cm) | 0.07 | 0.18 | 0.25 | 0.50 | 0.63 | 0.88 | 1.04 | 1.24 | 1.38 |
| GM12-N20-07310-12.0V Technical Specifications | |||||||||
| Parameter | Value 1 | Value 2 | Value 3 | Value 4 | Value 5 | Value 6 | Value 7 | Value 8 | Value 9 |
|---|---|---|---|---|---|---|---|---|---|
| Reduction Ratio | 50 | 100 | 150 | 210 | 250 | 298 | 330 | 380 | 1000 |
| Gearbox Length (mm) | 9 | 9 | 9 | 9 | 9 | 9 | 9 | 9 | 12 |
| No-load Speed (rpm) | 460 | 230 | 153 | 110 | 92 | 77 | 70 | 61 | 23 |
| Rated Speed (rpm) | 410 | 205 | 137 | 98 | 82 | 69 | 62 | 54 | 21 |
| Rated Torque (kg.cm) | 0.06 | 0.12 | 0.15 | 0.21 | 0.25 | 0.30 | 0.33 | 0.38 | 0.60 |
| Stalling Torque (kg.cm) | 0.55 | 1.10 | 1.38 | 1.93 | 2.30 | 2.74 | 3.04 | 3.50 | 5.52 |
Established in August 2009, this high-tech enterprise integrates the research, development, production, and marketing of micro motor series products. The primary product portfolio includes: various precision DC motors, stepper motors, reduction motors, planetary reduction motors, and brushless motors.
These micro motors are widely applied in medical equipment, medical detection and analysis, financial security, 5G applications, automotive appliances, intelligent communication, iris technology, AI intelligence, smart grid, smart home, commercial intelligent locks, smart switches, smart medicine cabinets, fresh food cabinets, smart wear, outdoor equipment, intelligent robots, electric tools, beauty tools, and more.
Since its inception, the company has consistently adhered to the philosophy of "people-oriented, pioneering and innovative spirit." Supported by a young, pragmatic, professional, and efficient team, the factory utilizes advanced production facilities, efficient management systems, and rigorous quality assurance processes. These combined capabilities allow us to support customers' requirements for continuously improving product performance, reducing energy consumption, facilitating production, and optimizing overall operational efficiency.
