Axon Motor
1 / 5
Main features:
| GM16-030PB-11158-3.0V | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Reduction | 6 | 20 | 52 | 85 | 118 | 170 | 215 | 250 | 297 |
| Length(mm) | 11 | 11 | 11 | 11 | 11 | 11 | 11 | 11 | 11 |
| No-load speed(rpm) | 1250 | 375 | 144 | 88 | 64 | 44 | 35 | 30 | 25 |
| Rated speed(rpm) | 1108 | 333 | 128 | 78 | 56 | 39 | 31 | 27 | 22 |
| Rated torque(kg.cm) | 0.01 | 0.03 | 0.06 | 0.10 | 0.12 | 0.17 | 0.22 | 0.25 | 0.30 |
| Stalling Torque (kg.cm) | 0.08 | 0.22 | 0.50 | 0.81 | 0.94 | 1.35 | 1.71 | 1.99 | 2.36 |
| GM16-030PB-05700-24V | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Reduction | 52 | 85 | 118 | 170 | 215 | 250 | 297 | 360 | 1000 |
| Length(mm) | 11 | 11 | 11 | 11 | 11 | 11 | 11 | 11 | 13.2 |
| No-load speed(rpm) | 260 | 159 | 114 | 79 | 63 | 54 | 45 | 38 | 14 |
| Rated speed(rpm) | 213 | 131 | 94 | 65 | 52 | 44 | 37 | 31 | 11 |
| Rated torque(kg.cm) | 0.16 | 0.26 | 0.30 | 0.43 | 0.54 | 0.63 | 0.74 | 0.90 | 1.50 |
| Stalling Torque (kg.cm) | 0.79 | 1.29 | 1.49 | 2.15 | 2.72 | 3.16 | 3.76 | 4.56 | 7.59 |
Established in August 2009, this high-tech enterprise integrates the research and development, production, and marketing of micro motor series products. The main products include: various precision DC motors, stepper motors, reduction motors, planetary reduction motors, and brushless motors.
Micro motors are widely used in medical equipment, medical detection and analysis, financial security, 5G applications, automotive appliances, intelligent communication, iris technology, AI intelligence, smart grid, smart home, commercial intelligent locks, smart switches, smart medicine cabinets, fresh food cabinets, smart wear, outdoor equipment intelligent robots, electric tools, beauty tools, etc.
Since its establishment, the team has adhered to the concept of "people-oriented, pioneering and innovative spirit". After eleven years of rapid development, it has a group of young and pragmatic, professional and efficient work teams, advanced production facilities, efficient management, excellent quality, and high-quality services to meet customers' needs of continuously improving product levels, reducing energy consumption, facilitating production, and improving efficiency, winning more and more recognition from customers.
Our standard Minimum Order Quantity (MOQ) is 500 pcs per order. For customized requirements or sample trials, please consult our engineering team for feasibility.
Yes, we provide extensive customization options for output shafts. We can manufacture D-cut shafts, M3 or M4 threaded shafts, round shafts, or other specific custom configurations to match your mounting design.
The motor supports a wide rated voltage range, including DC 1.5V, 3V, 4.5V, 5V, 6V, 9V, 12V, and 24V, ensuring compatibility with various power supplies.
Yes, we support the integration of magnetic encoders for speed and position feedback controls, making it ideal for precision smart applications.
We supply carbon brush, graphite brush, and precious metal brush commutations, allowing you to select the appropriate lifetime and noise parameters according to your application scenario.
They are widely applied in smart home appliances, smart medical devices, automated commercial locks, robotic drives, iris technology sensors, financial security devices, and outdoor electric tools.
