Small Brush DC Gear Motor 12V-24V Permanent Magnet 555 Model for Smart Home & Home Appliances 7-8W

Product Description

Products Description
555 Small DC Motor Specifications
Model RS-555 dc motor
Stator Diameter 35.8*57mm
Shaft Diameter 3.175mm
Shaft shape D-shaped, round shaft, double shaft
Output shaft length 10–15 mm (customizable)
Voltage 12V/24V DC
No-load Speed 3000~25000 rpm
No-load current 0.3–1.2 A
Rated current 1.5–3.5 A
Mounting holes 2-M3.0*0.5
Encoder 2ppr, 7ppr, 11ppr
Weight 150–180 g
Noise Level 45–55 dB (depending on load)
Application areas Automatic coffee machines, vacuum cleaners, automotive equipment, smart home devices
DC Motor Dimension Diagram DC Motor Front View DC Motor Back View
Recommend Products
Recommended Motor Model A Recommended Motor Model B
Motor raw materials
High Quality Motor Raw Materials
Production Equipment
Production Facility 1 Production Facility 2 Production Facility 3
Profile
Factory Overview
We were established in August 2017. It is a high-tech enterprise that integrates the research and development, production, and marketing of micro motor series products. The main products include: various precision DC motors, stepper motors, reduction motors, planetary reduction motors, brushless motors. Micro motors are widely used in medical equipment, medical detection and analysis, financial security, 5G applications, automotive appliances, intelligent communication, iris technology, AI intelligence, smart grid, smart home, commercial intelligent locks, smart switches, smart medicine cabinets, fresh food cabinets, smart wear, outdoor equipment, intelligent robots, electric tools, beauty tools, etc. Since our establishment, we have adhered to the concept of "people-oriented, pioneering and innovative spirit". After eleven years of rapid development, we have a group of young and pragmatic, professional and efficient work teams, advanced production facilities, efficient management, excellent quality, and high-quality services to meet customers' needs of continuously improving product levels, reducing energy consumption, facilitating production, and improving efficiency, winning more and more recognition from customers.
Certifications
Product Quality Certifications
Application Scenario
Motor Application Scenarios Overview
Application Field Specific Uses & Devices
Medical equipment Sphygmomanometer, massaging mattress, air pump, urine analyzer.
Business Machines Intelligent robot, copiers and scanners, 3D printers, tattoo pen.
Electric powered equipment Electric toothbrush, electric tool, adult products, electric toy car, electric curtain.
Smart Home Intelligent window opener, vacuum cleaner, smart coffee machine, hair drier, fascia gun, fan, air cleaner, hair removal device, door lock.
Food and Beverage Hand blenders, mixers, coffee machines, food processors, juicers, fryers, ice makers.
Robotics Servicing robotics, food delivery robot, reception robot, medical serving robot, AGV & AMR, conveying robot, inspection robot.
Global Market Distribution
Market Distribution Graph 1 Market Distribution Graph 2 Market Distribution Map
Frequently Asked Questions
Q: What are your main products?
A: We currently produce Brushed DC Motors, Brushed DC Gear Motors, Planetary DC Gear Motors, Brushless DC Motors, Stepper motors and Coreless Motors, etc. You can find detailed specifications for these motors on our product pages.
Q: How do I select a suitable motor?
A: If you have motor pictures or engineering drawings to share, or detailed specifications like voltage, speed, torque, motor dimensions, duty cycle, expected lifespan, and noise level requirements, please let us know. We will recommend the most suitable motor based on your parameters.
Q: Do you offer customization options for standard motors?
A: Yes, we can customize voltage, speed, torque, and shaft configurations (length and shape). If you require specialized wiring/cables, terminal connectors, capacitors, or EMC suppression, we can integrate these as well.
Q: How do you ensure product quality?
A: We follow a rigorous quality management process. Incoming raw materials are inspected against confirmed samples and technical drawings. During production, we conduct in-process quality audits, followed by a final comprehensive inspection on finished goods prior to shipping.
Q: What is the typical lead time?
A: Generally, production for standard motor models takes approximately 25-30 days. Lead times for highly customized products may be longer. We maintain flexibility in our production schedules to align with customer delivery requirements.
Q: What certifications do you hold?
A: We currently hold CE, RoHS, ISO13485, IATF16949, and REACH certifications.
